| Heat Pump Buffer Water Tank 30~150 Liters | |||||
| Model | 30 L | 60 L | 80 L | 100 L | 150 L |
| Inner Tank Diameter | Φ370 mm | ||||
| Outer Tank Diameter | φ470 mm | ||||
| Inner Tank Material | SUS 304 -1.2mm | ||||
| Outer Tank Material | Painted Galvanized Steel - 0.55mm | ||||
| Insulation Layer | High Density Polyurethane 50mm | ||||
| Circulation Connection | DN32 | DN40 | |||
| Unit Size | 470*370 mm | 470*650 mm | 470*840 mm | 470*1020 mm | 470*1470 mm |
| Package Size | 520*520*450 mm | 520*520*730 mm | 520*520*920 mm | 520*520*1100 mm | 520*520*1550 mm |
| Optional Coil | For Solar Heating System or Boiler | ||||
| Optional Accessories | Electric Heating ,Air Vent Valve, Safe Valve, Pressure Gage, Expansion Tank , Water Refill Valve ect . | ||||
| Heat Pump Buffer Water Tank 200~500 Liters | |||||
| Model | 200 L | 250 L | 300 L | 400 L | 500 L |
| Inner Tank Diameter | Φ440 mm | φ470 mm | φ470 mm | 550 mm | φ600 mm |
| Outer Tank Diameter | φ540 mm | φ570 mm | φ570 mm | 650 mm | φ700 mm |
| Inner Tank Material | SUS 304 -1.5mm | SUS 304 -2.0mm | |||
| Outer Tank Material | Painted Galvanized Steel - 0.55mm | ||||
| Insulation Layer | High Density Polyurethane 50mm | ||||
| Circulation Connection | DN40 | DN50 | |||
| Unit Size | 540*1500 mm | 570*1560 mm | 570*1840 mm | 650*1890 mm | 700*1890 mm |
| Package Size | 600*600*1580 mm | 620*620*1640 mm | 620*620*1920 mm | 710*710*1970 mm | 760*760*1970 mm |
| Optional Coil | For Solar Heating System or Boiler | ||||
| Optional Accessories | Electric Heating ,Air Vent Valve, Safe Valve, Pressure Gage, Expansion Tank , Water Refill Valve ect . | ||||
